Towbar - foldable, Australia
The towbar from the Škoda Genuine Accessories range is made of high quality materials, has undergone load tests and rigorous testing for strength and corrosion resistance.
The towbar complies with the…
Read more
The towbar from the Škoda Genuine Accessories range is made of high quality materials, has undergone load tests and rigorous testing for strength and corrosion resistance.
The towbar complies with the homologation and all Czech as well as international regulations.
The simple automatic mechanism for attaching and removing the tow arm requires no tools, making it as easy as possible to comply with the legal obligation to remove the tow arm when no trailer is attached.
When travelling abroad with the towbar without a trailer attached, the legal regulations of the relevant country must always be observed.
A detailed description of how to operate the tow arm is given in the Owner's Manual.
This tow bar is designed for vehicles with preparation for tow bar, PR UN.ECE (NI1/NI7/NI8/NI9), ICE (0K0)/mHEV(0K4) in equipment.
For fitting, it is necessary to order the following parts from the Škoda Original Parts catalogue:
- Control unit 5E3 055 713,
- Glue 1 pc / D 428 000 M2
Technical specifications
- Product code
- 57H092160E
- Color
- Black
- Material
- High strength steel
- Dimensions
- 1390 x 690 x 250 mm
- Content of set
- Towbar with wiring, screw (4 pcs), label (57H 092 190B), bolt (2 pcs), switch for electric release, switch cover, frame, user manual
- Notice
- The maximum towing weight of the (non/braked) trailer and the maximum vertical load on the ball stud are specified in theVehicle Owner's Manual. Maximum vertical load: 100 kg Maximum vertical load when using accessories: 75 kg
- Weight
- 26 kg
