Tow bar Superb IV
The towbar from the Škoda Original Accessories range is made of highquality materials and has been subjected to stress tests and rigorous tests for strength and corrosion resistance.
The towbar compli…
Read more
The towbar from the Škoda Original Accessories range is made of highquality materials and has been subjected to stress tests and rigorous tests for strength and corrosion resistance.
The towbar complies with homologation E13*55R-02*8320 and all Czech and international regulations. A simple automatic mechanism ensures that the towing arm is folded into the functional position and then folded back under the bumper when not in operation.
This towing device is designed for vehicles with PR number:
1. ICE (0K0)/ (0K4) mHEV, with preparation for towing device (1M5) and vehicles with chassis (UB1) Sportline / (1JA) Normal / (1JC) Sport / (1JP) DCC and for UN.ECE vehicles (NI1 / NI7 / NI8 / NI9)
or
2. ICE (0K0)/ (0K4) mHEV, with preparation for towing device (1M5), with raised chassis (UC7), with weight range for rear axle (0YC/0YD/0YE/0YF/0YG), for UN.ECE vehicles (NI1/NI7/NI8/NI9)
For installation, it is necessary to order from the Škoda Original Parts catalogue:
- Electrical installation kit 5E3055204A
- Adapter 3P0055202D
For Superb Combi IV
-Bumper mounting rail 3J0807863A
For the Superb Limo IV
-Plastic reinforcement 3P3867730A 4PK
-Glue (Teroson 2444) D428000 M2
We recommend all related assembly work to be carried out by authorized Škoda Auto partners.
Associated products
Towbar adapter - from 13-pin to 7-pin socket EAZ 000 001
Technical specifications
- Product code
- 3P0092160
- Material
- Quality steel
- Dimensions
- 1120 x 620 x 220 mm
- Content of set
- Towing bracket, bolt (4 pcs), control unit 5H2.907.383.D, expansion nut (2 pcs.), switch, user manual
- Professional installation recommended
- Yes
- Warning
- Always check the correct activation procedure in ETKA. Can not be fitted on vehicles exported to Australia. For vehicles manufactured until CW 27/2025.
- Restrictions
- Cannot be retrofitted to vehicles without preparation with PR number 1D0. Not applicable for PHEV vehicles. Can not be fitted on vehicles exported to Australia. For vehicles manufactured until CW 27/2025.
- Notice
- Technical specifications: Maximum towing weight - The weight limit for the (braked/unbraked) trailer is specified in the vehicle‘s technical certificate. Theoretical reference force (Dc - Wert) - 11,3 kN. Maximum vertical load: When using a trailer - 90 kg. When using accessories - 75 kg. Always depends on the technical parameters of the specific vehicle.
- Weight
- 25 kg
Designed for:
Notice
To verify compatibility with your vehicle and the possibility of installation, please first contact an authorized Škoda service partner or our Infoline with the VIN code of the vehicle.
