Tow bar – foldable
The tow bar from Škoda Genuine Accessories is made of high-quality materials and has been subjected to stress tests and rigorous tests for strength and corrosion resistance. The towbar complies with ho… Read more
The tow bar from Škoda Genuine Accessories is made of high-quality materials and has been subjected to stress tests and rigorous tests for strength and corrosion resistance. The towbar complies with homologation and all Czech and international regulations. A simple automatic mechanism ensures that the towing arm is folded into the functional position and then folded back under the bumper when not in operation.
This tow bar is designed for vehicles with preparation for tow bar (1M5),UN.ECE (NI1/NI7/NI8/NI9) in equipment:
1. ICE (0K0)/ mHEV (0K4) and with chase Sportline (UB1) / normal (1JA) /sport (1JC) / DCC (1JP)
or
2. ICE (0K0) / mHEV (0K4) and with chase Hochstand (UC7) and with weight range for rear axle 0YC/0YD/0YE/0YF/0YG.
For installation, it is necessary to order from the Škoda Original Parts catalogue:
Control unit 5E3 055 713
Electrical installation kit 5E3 055 204A (only for vehicles manufactured up to CW 47/2025)
Adapter 3P0 055 202D (only for vehicles manufactured up to CW47/2025)
For Superb IV Combi:
- Bumper mounting rail 3J0 807 863A
For the Superb IV Limo model:
- Plastic reinforcement 3P3 867 730A 4PK
- Switch cover 5G0 868 345 4PK
- Glue D 428 000 M2
We recommend all related assembly work to be carried out by authorised Škoda Auto partners.
Technical specifications
- Product code
- 3P0092160J
- Material
- Quality steel
- Dimensions
- 1120 x 620 x 220 mm
- Content of set
- Towing bracket, bolt (4 pcs), expansionnut (2 pcs.), switch for electric release, switch cover,production label for towbar 3P0 092 190, user manual
- Professional installation recommended
- Yes
- Restrictions
- Cannot be retrofitted to vehicles withoutpreparation - PR number 1D0. Not applicable for PHEV vehicles. Only for vehicles exported to Australia. Only for vehicles produced from CW 28/2025.
- Notice
- Technical specifications: Maximum towing weight - The weight limit for the (braked / unbraked) trailer is specified in the vehicle's technical certificate. Theoretical reference force (Dc - Wert) - 11,3 kN, Maximum vertical load: When using a trailer - 90 kg; When using accessories - 75 kg. Always depends on the technical parameters of the specific vehicle.
- Weight
- 25 kg
