Rear view camera Fabia IV
The rear view camera from Škoda Genuine Accessories displays the image of the situation behind the car on the infotainment screen, offering another level of situational awareness in addition to the pa… Read more
The rear view camera from Škoda Genuine Accessories displays the image of the situation behind the car on the infotainment screen, offering another level of situational awareness in addition to the parking sensors. This genuine set matches the camera that’s fitted as an factory option, including full functionality and comfort. For the camera’s installation - vehicle must be equipped with the infotainment system.
The parking camera is integrated into the fifth door handle. The camera is fitted with a washer nozzle and the camera lens is cleaned automatically when the rear windscreen washer is activated.
A detailed description of the parking camera’s operation can be found in the vehicle’s user’s manual.
This set is intended for UN.ECE Fabia IV vehicles manufactured from CW 48/2024, with left-hand drive (PR L0L) or right-hand drive (PR L0R), and with the required PR equipment:
NI1 or NI7 or NI8 or NI9 (UN.ECE).
Inquiry this product at local reseller
Technical specifications
- Product code
- 6VE054634D
- Placement
- In the fifth door handle.
- Warning
- Considering the difficulty of the installation and subsequent activation of the parking camera, the installation needs to be completed by Škoda authorized partners.
- Content of set
- Wiring harness in the car interior Wiring harness of the 5th door, Washer hose, Handle with the reversing camera, Jumper, Fuse, 7.5 A, MINI, Push-in clamp 5 pcs, 2-PIN terminal block, Cable tie 65 pcs, Terminal block holder 2 pcs, 6-PIN terminal block counterpart 2 pcs, Foam damping small 2 pcs, Polyurethane foam adhesive tape 9 pcs, Foam damping large 2 pcs, Connector 3 pcs, T-piece, Cable tie large 5pcs, Cable tie with hole fixing lug, Cable tie small, Fitting instructions
- Professional installation recommended
- Yes
- Weight
- 1,5 kg
- Notice
- Technical specifications: The rear view camera is automatically activated when the vehicle is shifted into reverse gear. The camera simultaneously displays the area behind the vehicle and guide lines corresponding to the width of the vehicle. The camera features a parking assistant, which shows the driver a parking space of the required size behind the vehicle and then provides them with parking assistance. This assistance is automatically cancelled if the steering wheel is not turned in the appropriate direction for a long period of time. The parking manoeuvre must then be started again.
